Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: CVR
  • Model Number: W-210A & W-250A
  • size:: 2x10" passive line array
  • cabinet:: birch plywood
  • driver:: Neodymium
  • power handling: 660watt each box
  • Painting: textured painting ,waterproof
  • warranty: 1 year free warranty
  • brand: CVR
  • Connector: NEUTRIK NL4
  • Venus: indoor or outdoor

Packaging & Delivery

Packaging Details: carton box or flight case
Delivery Detail: 7 to 10 days after signing the contract

Specifications

1.passive,line array system
2.10'x2 neodymium drivers
3.Birch plywood,Water-proof painting
4.CE
5.good after-sales

concert/stage speaker elements line array system

W-210A is a line array system which is made of two 10” neodymium woofers, two 2” titanium neodymium compression drivers and high-performance low-distortion compression driver with innovative horn design of waves phase philosophy. It is a zero interfere line array with multi- speaker combined to produce accurate directivity and maximum dynamic impact. Wherever low frequency extension is required, a W-210A will integrate seamlessly with W-250A line array sub-bass system in a standard configuration. Each enclosure is equipped with rigging system, allowing flown array to be constructed rapidly and safely. W-210A is very versatile and scalable for a wide range of applications in touring performance, corporate and fixed installation fields.
DESCRIPTION and APPLICATION
W-250A is dedicated high performance sub-bass system designed to augment the low frequency output of the W-210A, W-250A is a sub-bass enclosure which must be flown with W-210A. So its physical dimensions are identical to the W-210A and it is equipped with the same proprietary rigging system. It features with twin 15” neodymium woofers with magnet structure and suspensions engineered for maximum linear excursion.


Model

W-210A/W-250A

Type

Line array system

Line array sub-bass system(W-250A)

Frequency Response

55Hz-20KHz±3dB

40Hz-150Hz±3dB(W-250A)

Directivity index(Dl)

12(±2)1.2KHz-16KHz

Power handing

LF 500W(RMS)1000W(PEAK)

HF 160W(RMS)320W(PEAK)

1200W(RMS)2400W(PEAK)(W-250A)

Sensitivity

LF 99dB(1W@1M)

HF 108dB(1W@1M)

112dB(1W@1M)(W-250A)

MaxS.P.L

LF 127dB(PEAK/1M)

HF 127dB(PEAK/1M)

143dB(PEAK/1M)(W-250A)

LF section

2×10"(260mm) neodymium woofer

75mm(3in)coil

Components

2×15"(380mm)  woofers

100mm(4in)coil(W-250A)

Nominal impedance

16 ohm

4 ohm(W-250A)

HF section

2×2"neodymium compression driver

with 51mm titanium diaphragm

Nominal impedance

16 ohm

Output section

2-channel

Dispersion pattern

110°H×9°V

Finish

Water-proof,wear-resistant textured black paint

Array design

Arrays of less than 3×W-210A will

provide poor dispersion control and

are neither recommended nor supported

Speaker cables

LF 1(+)1(-) HF 2(+)2(-)

1(+)1(-) (W-250A)

Rigging system

Please refer to the W-210A user

manual before any operation

Input connectors

2×NL4MP speakon

Recommend crossover

LF 45Hz-1200Hz

HF 1200Hz-20KHz

35Hz-120Hz(W-250A)

Dimensions

855×293×600mm(W×H×D)

855×440×820mm(W×H×D)(W-250A)

Package dimensions

925×360×670mm/0.22cbm

925×510×890mm/0.42cbm(W-250A)

Enclosure

Birch plywood

Net weight

42kg (W-210A)/ 81kg (W-250A)

Gross weight

45kg (W-210A)/ 84kg (W-250A)
















About us:
Guangzhou CVR Pro-Audio Factory is a manufacturer specialized in producing professional audio equipment with an own brand “CVR ” since 2005. Our 5,000 square meters plant has R&D, sales and demonstration departments. Fully equipped demonstration facilities are available with knowledgeable staffs. CVR PRO AUDIO can easily provide a wide range of professional sound like:PA speaker, indoor and outdoor line array speaker, subwoofer, floor monitor, power amplifier and speaker management system. From the smallest conference room to the largest stadium. We would look forward to be your supplier on pro sound in china.
